3-in-1 Design

The Squiggles+ Stander is an extremely versatile 3-in-1 stander, offering prone, upright and supine standing in one product. Prone position provides anterior support and stability while encouraging weight-bearing and use of upper extremities. The upright position is designed for users with good balance and trunk control but cannot stand independently. Supine position supports the back of the body while offering lateral and anterior supports to maintain alignment.

Hip Abduction

Hip Abduction now achievable, 60 degrees bilaterally. With a measurement gauge to monitor and aid repeatability. Hip laterals also shift in sync with the legs as they move through the arc of abduction.

Advanced Knee Support Design

Larger, more comfortable medial knee supports to distribute pressure, especially in abducted standing. Advanced wrap support to maintain knee in neutral flexion or extension.

Independent Footplates

Individually adjustable footplates allow you to set each footplate to different heights. This accommodates leg length discrepancies while providing support to both legs.

Improved Pivot Base

Improved pivot base accommodates hip abduction and facilitates horizontal loading from 90 to 160 degrees. The new foot pedal eases caregiver effort while providing a more stable platform to transfer the child onto.

Activity Tray

Activity tray with improved height and adjustability accommodates the smallest users. Whether prone or supine, the tray with optional grab rail can be used to facilitate table top activities while in the standing position.

Height-Adjustable Push Handle

New height-adjustable push handle helps make positioning the child during standing therapy, easier. The height-adjustable push handle can be folded for ergonomic use and lowered for prone use.

Please note: Trial units available in purple only. Blue, Red and Red Vinyl are indent only.

Contact your Business Territory Manager or email helpis@alliedmedical.co.nz for more information or to book in a demonstration.

Approx Age Range	1-5
User Weight Limit	22kg
User Height	730mm - 1110mm
Chest Support Angle Adjustment	+/-30°
Chest Support Depth Adjustment	50mm
Chest Plate Height Range	460mm - 820mm (footplate to armpit)
Width Between Chest Laterals	160mm - 230mm
Tray Height Prone (footplate to top of tray)	555mm - 800mm
Tray Height Supine (footplate to top of tray)	480mm - 800mm
Tray Angle Adjustment Prone	30°
Tray Angle Adjustment Supine	40°
Warranty	3 years
Hip Support (height from footplate to mid buttocks)	300mm - 530mm
Distance Between Midline of Knees	140mm - 215mm

What is the length and width of the Squiggles Plus standing frame?

The chest support height (distance from footplate to armpit) has a minimum length of 560 mm and a maximum length of 940 mm.

The hip support height (distance from the footplate to the mid-buttock) has a minimum length of 400 mm and a maximum of 640 mm.

The chest / Hip width has a minimum length 160 mm and a maximum length of 230 mm.

Can Leckey products be wiped down with V Wipes?

These are safe to use on metal and plastic parts, but recommend you don't use them on harnesses or cloth coverings.

What are the differences between the Leckey Ankle Huggers and the Ankle Wraps?

From a Clinical perspective, there is no significant functional difference between these two options. Differences are largely aesthetic and personal choice of the user and their families.

Ankle Huggers may be more practical when other footwear ie. AFOs, Orthotic boots is required. The ankle wraps can fit onto Leckey sandals for a more uniform appearance.

Can Stealth Headrests be used on Leckey Products?

Yes, they be attached the Leckey Horizon Stander and the Leckey MyGo Stander. Please chat to your Technical Product Specialist or call us on 0800 31 61 81 for more information.
